Aztec Airbrush Nozzle Cleaning Aztec airbrush nozzle cleaning tutorial covers cleaning the nozzle on a Aztek airbrush including taking it apart and putting it back together again. Written by by Allan Hull. If you own an Aztek airbrush you should find this article very help in keeping your airbrush working it perfect working order. Brought to you by Airbrush Technique Magazine. If you have an article you would like to have published on this web site please contact [email protected] toothbrush, dish soap, water, inkjet syringe, toothpicks, container, water. Toothbrush dipped in soapy water works well to clean the outside of an Aztek tip. A toothpick dipped in cleaning solution can get the area surrounding the needle. Soaking the tip(s) in cleaning solution helps loosen crud. Rinse the head of the brush body in running water. Holding down the trigge run water through the nozzle opening. Gently push in, then pull out the needle/nozzle assembly to separate it from the tip body.

needle/nozzle separated from tip body The needle can be separated from the nozzle by gently pulling on the base of the needle. Soak the tip body and nozzle in cleaner while working on the needle. A toothbrush makes cleaning the needle much easier. Stick a fingernail between the spring coils and “unscrew” the needle to free crud stuck between the needle and the spring. An inkjet syringe simplifies flushing the nozzle with cleaner. Crude found inside the nozzle. A toothpick can also help scrub a nozzle clean. Scrub the tip body with a toothbrush and cleaner. Put needle back inside the nozzle and nozzle inside tip body. Rotate nozzle until the flutes line up with groove inside the tip body. After the flutes are lined up with the groove, the nozzle will drop down inside the tip body. Gently push the nozzle to seat it inside the tip body. Put tip back on airbrush and flush with clean water. Some tips have recessed needles, a toothbrush or toothpick dipped in cleaner can clean off minor tip dry during production.

, Inc. Reserved No part of this tutorial may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, electrostatic, magnetic tape, mechanical or otherwise, without prior permission in writing from Airhead Airbrush. Aztek Cleaning Station Airbrush SetDetailsAztek Airbrush Cleaning Station Filters FREE Shipping on orders over $49. DetailsAztek Acrylic Airbrush Cleaner, 4-Ounce 4 x 2.4 x 4 inches 12 ounces (View shipping rates and policies) #102 in Toys & Games > Hobbies > Hobby Building Tools & Hardware > Painting Tools I like using this when I'm not in my airbrush studio. Keeps airbrush fumes from getting over everything.The Aztek company produces quality airbrush painting systems and components. The simple design of the Aztek system incorporates a needle and jet within the paint nozzle itself. This allows for quick cleaning and differing painting effects. When using Aztek nozzles, there is no need to strip the whole airbrush down.

Users can simply unscrew, clean, change, and resume painting. Aztec nozzle ranges are acceptable for all types of paint. They can be brought down to a fine line or adjusted for larger coverage. The first airbrush was invented and patented in 1876 by Frances Edgar Stanley of Massachusetts. spray car wash ann arborStanley’s design was a crude one that was later rebuilt by Abner Peeler. harley police air cleaner insertHe developed it for the painting of watercolors and various other artistic purposes. ionic air purifier youtubePeeler’s design was very basic at first. It was based on numerous spare parts from a jeweler's workshop such as welding torches and old screwdrivers. It took many years of continued development before a usable prototype was created by Liberty Walkup of Illinois.

Walkup patented his version of the machine using the name airbrush as a moniker. Interestingly, Walkup and his wife taught the airbrushing technique to the Impressionist painter Wilson Henry Irvine at the Air Brush School in Rockford, Illinois. There are many types of Aztek nozzles. These nozzles are color-coded, named, and numbered. They each perform a wide range of functions. To help select an Aztek nozzle for a particular function, the following is a reference chart that outlines the color, name, size, and paint coverage of each nozzle. Produces fine detail work, dot work, and very fine mists Gray General Purpose 9305C Used for medium areas of coverage Turquoise High Flow 9306C Used for illustration, large areas of coverage, and washes Produces textures, special effects, and uneven stippling Covers small to medium areas such as camouflage Orange Medium Coverage 9343C Used for medium coverage areas such as T-Shirts and crafts Yellow Large Coverage 9344C

Covers large areas such as model car and truck bodies Black Acrylic General Purpose 9340C Produces a medium area of coverage that's often used in illustration White Acrylic High Flow 9341C Produces a medium area of coverage Aztek sets include the airbrush, hose, nozzles, and everything that is needed to get beginning users of the Aztek airbrush systems started on a more efficient way to create art. The kits contain the airbrush, paints, nozzles, and cups. This kit comes packaged in a wooden presentation box that includes a set of six Aztek nozzles. Features of this set include: • Double action controls and an internal mix airbrush • Lightweight and durable body • Pinpoint accuracy • Function as a double or single action airbrush • Patented Aztek nozzle for swift effects and changes • General and precise detail work options This set also comes packaged in a wooden presentation box and has all the features of the other set. The difference between the two sets is that this one includes a set of nine Aztek nozzles.

Here are some of the other accessories that can be incorporated with the Aztek system. This cleaning station has an adjustable neck. A cleaner is blown through the airbrush and trapped in the jar. This station also accommodates different brands of airbrushes. These cups are used for fast color changes. They can be removed from the airbrush without having to be emptied. Their sizes range from 1.0 cc to 12.0 cc. It is quite easy to find Aztek airbrush nozzles on eBay. The Home & Garden category has an art section. Click on the Art Supplies area of this category. This should bring up a menu that will include an Airbrushing choice. Buyers should be able to find what they need in this section. Another way to find these nozzles is to search for them by the brand name and serial number. Because airbrushes and nozzles can be purchased individually, referencing the chart that lists their unique serial numbers will help to locate them. Many sellers offer free shipping on their items, which makes shopping on eBay an economical choice.
